PMK ENVI® Extreme Temperature Passive Probe for Environmental Testing
The PMK ENVI® Extreme Temperature Passive Probe is ideal for environmental testing, and measurements in climate chambers from -55°C to +200°C.
- 500MHz Bandwidth
- 400V /1250V peak
- High Input Impedance 4.5MOhms
- Replaceable String or Rigid Tip
- Universal use with BNC connector
- Wide range of High Temperature accessories
The PMK ENVI® Passive Probe is ideal for environmental testing, and measurements in climate chambers from -55°C to +200°C. The world's first modern probe for this high temperature range with 400V / 1250V peak input voltage range, 10:1 divider and 500MHz bandwidth is suitable for a variety of applications. Individual contacts with high signal fidelity in different applications is ensured with the replaceable spring tip and a variety of contacting accessories. With its BNC connector with divider read-out function the probe is universally connectable to any oscilloscope with 1 MΩ BNC input including automatic scaling on the oscilloscope display.
All probes are calibrated at the end of production. The factory calibration certificate is optional.
Models & Specifications
|
Order number |
Article |
Attenuation |
Bandwidth (-3 dB) |
Input Voltage |
Input Impedance |
Rise time |
Temperature Range |
|---|---|---|---|---|---|---|---|
|
835-312-Z01 |
ENVI® PHT |
10:1 |
500 MHz |
400V / 1250V peak |
4.5 MΩ / 20 pF |
1.2 ns |
-55°C - +155°C |
|
835-312-U01 |
ENVI® PUHT |
10:1 |
500 MHz |
400V / 1250V peak |
4.5 MΩ / 20 pF |
1.2 ns |
-55°C - +200°C |
|
KAL-ENVI |
Calibration Certificate |
PMK ENVI® Datasheet
