GoGo Instruments ECH600 Electrical Heating and Cooling Stage JS

The GoGo Instruments ECH600 is a precision electrical heating and cooling stage designed for temperature-dependent electrical characterisation of advanced materials, semiconductor devices, thin films, and electronic components. Combining cryogenic cooling with high-temperature operation, the platform delivers stable thermal control from −190 °C to +600 °C while supporting low-noise electrical measurements under controlled environmental conditions.

Key Features

• Wide temperature range: −190 °C to +600 °C
• Temperature stability of ±0.1 °C
• Rapid thermal ramping up to 150 °C/min
• Liquid nitrogen cooling and resistive heating
• Reflection and transmission optical configurations
• Four precision electrical probe interfaces
• Compact low-profile stage design
• Optional vacuum chamber configuration
• Professional programmable temperature control software
• SDK support for LabVIEW, C#, and automation integration
• Customisable hardware and probe configurations available

Optical Access and Stage Design
The ECH600 supports both reflected-light and transmitted-light experimental configurations, enabling combined electrical and optical analysis. The compact low-profile design enables integration with optical microscopes, spectroscopy systems, and customised in-situ measurement platforms.

Typical Applications

• Semiconductor reliability analysis
• Variable-temperature conductivity testing
• Thin-film transport measurements
• Electrical characterisation of nanomaterials
• Quantum material studies
• Dielectric spectroscopy
• Optoelectronic device testing
• Cryogenic material analysis
• In-situ microscopy with electrical biasing
