Zygo NewView™ 7100
The NewView 7000 and following 8000 series are no longer available. They have been superseded by the NewView 9000 series. Accessories and objectives are still available.
The Zygo NewView 7000 Series of Optical Profilers are no longer available. They have been superseded by the NewView 8000 series, the Nexview and the ZeGage series. Most accessories and objectives are still available.
Zygo NewView 7000 Series Scanning White Light Interferometers (optical surface profiler) for Fast Non contact 3D measurement surface metrology for texture, roughness, flatness, step heights and MEMS device dimensions.
-
Zygo VeriFire MST Interferometer
The Zygo VeriFire MST utilises a wavelength shifting laser and patented data acquisition methods to enable simultaneous measurement of the front and back surface of transparent optics, thickness variation (including wedge) and simple 2-step homogeneity metrology without difficult part preparation or messy coatings. -
EverBeing SR-4-6L, Four-Point Prober, Sheet Resistivity, 4-Point Probe
£3,092.40 £1.00The SR-4 Four-Point Probe System is an easy-to-use tool for the rapid measurement of sheet resistance, resistivity, and conductivity of materials. To be used in conjunction with your existing Source Measure Unit (SMU) or current source and volt meter. Head Up/Down 10mm, Probing, Z Resolution = 1Micron.
-
EverBeing EB-050ER Micropositioner 1.0µm Resolution, Magnet On/Off, Right
£1,014.00 £1.00Our most popular Micropositioner offering true linear motion of 12mm in each axis X-Y-Z and 1.0µm resolution. Supplied in right hand version with Magnet On/Off Base for ease of placing and positioning on the platen.
Suitable for use with standard bracket or with soft landing inclination using our coaxial and triaxial tubular tip holders.
- Accuracy: 1.0micron (1.0µm )
- Base Type: Magnet on/off
- Precision linear bearings
- Travel X-Y-Z: 12MM * 12MM * 12MM
- Lead screw: 80 TPI (threads per inch)
- Right hand Version
- Dimensions: 52mm(W) x 96mm(D) x 76mm(H)
- Weight: 550g
The EB-050 series is available in left and right hand versions with Permanent Magnet (M), Magnet on/off (E) or Vacuum bases (V) to suit all applications. Also available in 100TPI for 0.7µm resolution.
-
EverBeing C-Series Probe Station, C-2, C-4, C-6, C-8
Celebrating over 30 years of manufacturing probe stations and micro positioners the C-Series are one of the world’s most popular and affordable, yet built with precision and repeatability.
They are 6 models in this series, starting at 2 inch chuck to 8 inch C2, C2-PLUS, C2-RF, C4, C6 and C8.
Fitted with a 10 micron precision X-Y chuck stage for alignment, hard chrome pated platen, vacuum chuck and anti-vibration mounts as standard, makes this compete with probe stations that cost many times the price. The 4 inch and above features chuck up/down. Available with a trinocular monozoom microscope.
