Sumix Manta C Microscope
- Single fibre inspection
- Multi fibre inspection
- Autofocus
- PASS/FAIL verdict
- Scratch detection
- High resolution
- Industry standards
- Connects to tablet or laptop
The Sumix Manta C is a wide field-of-view microscope probe for single-fiber inspection, designed to ensure cleanliness of the fiber end face and ferrule surface - ideal for large-fiber and large-core military connectors. It supports a broad range of connector types, including LC, FC, SC, MU, E2000™, CS®, SN®, MDC, Arinc, Avim, mini-Avim, SMA, high-power SMA, and MIL-spec termini, on both patch cord and bulkhead sides. MTP®/MPO inspection is available in two scans (2 seconds each). Suitable for field, lab and manufacturing environments, the Manta C is essential for quality control, incoming inspection, and network troubleshooting.
Wide field of view (2.26 × 1.27 mm)*
Check the fiber end face along with the surrounding ferrule surface. Inspect large fiber and large-core military connectors. * Compared to other handheld microscopes for single-fiber inspection.
High-resolution imaging
Achieve precise inspection results with 1.8 µm optical resolution and 0.59 µm/pixel camera resolution.
PM fibre inspection
Control and measure the angular alignment of the stress elements in polarisation-maintaining (PM) fibres.
Automatic focus
Capture sharp, repeatable images at the push of a button.
High-speed operation
Get a Pass/Fail report for a single-fiber connector in 1 second. Inspect MPO in two fast scans (~2 seconds each), with a manual shift in between.
SMX-Manta-C digital inspection system includes:
- Manta C microscope
- USB 3.0 cable
- Case
- MaxInspect™ analytical software
| Field of view: | 2.26 × 1.27 mm |
| Defect size detection: | 0.75 µm |
|
Effective resolution:
|
1.5 µm (based on MTF calculations) |
| Magnification: | 0.59 µm/px or 470× (Display 24" 1920 × 1080) |
| Focus: | autofocus |
| Measurement time: The indicated values do not include autofocusing time. |
1 sec for single fibre,
6.5 sec for MT12, 6.9 sec for MT16, 9.7 sec for MT24
(includes the time of manual shifting to the second part of fibres). |
| Light source: | royal blue LED, 447.5 nm |
| Camera type: | digital, USB3.0 |
| Sensor type: |
monochrome, 3840 × 2160, 1/1.8’’ CMOS
|
| Live image: |
23 fps at 3840 × 2160 px
|
| Power source: |
USB 3.0 port of PC
|
| Cable: | USB 3.0, detachable |
| Dimensions (H × W × L): |
77 × 28 × 249 mm (3 × 1.1 × 9.8 inches)
|
| Weight: |
491 g (1.08 lbs)
|
| Housing material: | aluminum alloy |
| Barrel material: | stainless steel |
| Operating temperature: | +5 to +35°C |
| Compatible with: | desktop PC, laptop, tablet |
PC System Requirements
| Operating system: | Windows 11, Windows 10 | |
| For viewing measurement results: | Microsoft™ Excel® 2010 or higher | |
| Recommended configuration | Minimal configuration | |
| Processor: | Intel Core i5 or higher | Intel Core i3 |
| RAM: | 4 GB | 2 GB |
| Video card: | Any with 24 bit True Color | Any with 24 bit True Color |
| Hardware interface: | Intel integrated USB 3.0 Host Controller.At least one USB 3.0 port for connection | Intel integrated USB 3.0 Host Controller.At least one USB 3.0 port for connection |
| Hard Drive: | 1 Gb or more | 1 Gb |
| Performance: | 500 Mflops or more | 400 Mflops |
Tablet system requirements
|
Operating system: |
Windows 11, Windows 10 |
|
|
Recommended configuration |
Minimal configuration |
|
|
Processor: |
Intel Core i7 |
Intel Core i5 |
|
RAM: |
4 GB |
2 GB |
|
Screen resolution: |
1280 × 800 px or higher |
1024 × 768 px |
|
Display size: |
10" or more |
8" |
|
Hardware interface: |
USB 3.0 |
USB 3.0 |
Sumix Manta C Microscope Datasheet
