SPECIAL OFFER - Pico Technology TA050 Attenuator Set
Availability: In stock
Product Code:
40447
Manufacturer:
Pico Technology
£64.80
£1.00
TA050 Attenuator set: 3-6-10-20 dB, 1 GHz 50 Ω 1 W BNC (m-f)
The Pico Technology TA050 attenuator set consists of four coaxial attenuators designed for use with signals up to 1 GHz. Each attenuator has a male and a female BNC connector.
Usage note
The TA050 attenuators must be used with a matched 50 Ω source and load. If you wish to attenuate a signal before feeding it into a high-impedance measuring instrument, you must add a 50 Ω feedthrough terminator such as the Pico Technology TA051 feedthrough terminator.
| Bandwidth | DC to 1 GHz |
| Attenuation | 3 dB, 6 dB, 10 dB, 20 dB |
| Maximum power dissipation | 1 W |
| Input impedance | 50 Ω |
| Output impedance | 50 Ω |
| VSWR | 1.5:1 or better |
| Dimensions | 56 x 20 x 17 mm (approximately 2.2 x 0.8 x 0.7 in) |
| Connectors | BNC, 1 male + 1 female |
| Construction | Shielded inner box with plastic shell |
| Weight | 24 g (approximately 0.85 oz) each |
We have no downloads available for this product.
