HAROGIC Technologies SAN-90 9GHz Compact Real-Time Spectrum Analyser/Receiver
Availability: In stock
Product Code:
83322
Manufacturer:
HAROGIC Technologies
£3,276.00
£1.00
The new HAROGIC SAN-90 is a USB-based spectrum analyser and receiver featuring a frequency range of 9kHz to 6GHz. Designed to deliver high performance on a budget with essential measurement functions such as channel power, automatic harmonics, phase noise, and AM/FM analog demodulation. Its highly compatible APIs facilitate seamless secondary development, offering customers exceptional versatility and value.
Key Features:
- High-performance superheterodyne receiver
- Frequency range:9 kHz to 9GHz
- IF and image rejection:>95 dBc(typ.)
- 1 GHz DANL:-168 dBm/Hz(typ.)
- 1 GHz phase noise:<-110 dBc/Hz@10 kHz(typ.)
- 1 GHz phase noise measurement:<-125 dBc/Hz@10 kHz(typ.)
- Analysis bandwidth:50 MHz/100 MHz(opt.50)(typ.)
- USB3.0/2.0 Type-C interface
- Core dimensions (L×W×H) ≤ 109 x 60 x 16 mm weight ≤ 195 g
| Model | Frequency | Phase Noise 1 GHz, 10 kHz offset | DANL 1 GHz, Amp On |
Analysis Bandwidth | Sweep Speed RBW=250 kHz |
| NEW SAN-45 | 9 kHz-4.5 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz（opt.50） |
≥1 THz/s |
| NEW SAN-60 | 9 kHz-6 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz（opt.50） |
≥1 THz/s |
| NEW SAN-90 | 9 kHz-9 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz（opt.50） |
≥1 THz/s |
| Code | Option | Description |
| 01 | Built-in OCXO reference clock | built-in hardware |
| 05 | Internal high precision GNSS | built-in hardware |
| 20 | AUXIO IO Expansion board | accessory |
| 34 | External omnidirectional antenna, 400MHz to 8000MHz, Gain<2dBi | accessory |
| 35 | External active directional antenna, frequency range: 0.5 to 10 GHz Gain: < 5 dBi (amp off); < 25 dBi(amp on) |
accessory |
| 40 | T1 temperature class | built-in hardware |
| 41 | T2 temperature class, only available for core | built-in hardware |
| 50 | 100 MHz analysis bandwidth | built-in hardware |
| 71 | Basic vector modulation analysis | software |
| 72 | Pulse analysis | software |
HAROGIC Technologies Spectrum Analyser Quick Start Guide
HAROGIC Technologies SAN Series Product Manual
HAROGIC Technologies SA/NX/PX Series User Guide
