HAROGIC Technologies PXE-200R, 20GHz Rugged Realtime Spectrum Analyser (RSA)
The new PXE-200R is a ruggedised version of the PXE-200, 20GHz ultra-portable handheld Realtime Spectrum Analyser (RSA). Weighing just 2.5 kg and a 10.1-inch all touch screen , this unit is built on the success of the SAE-200 unit. This is a great alternative to other handheld spectrum analysers on the market offering high performance in a small ultra-portable design. Combined with an impressive battery life over 3 hours is an excellent choice for field testing.
- IEC IP68 certified
- MIL-STD-810H method-512.6/514.8/516.8 certified
- Frequency range: 9 kHz-20 GHz SHR architecture, 19-segments pre-selected filters;
- Sweep speed > 900 GHz/s (RBW ≥ 300 kHz)
- Analytical bandwidth: 100 MHz (std.), 110 MHz (opt.)
- Standard preamplifier, DANL: -168 dBm/Hz (typ.)
- SSB Phase Noise: -100 dBc/Hz @10kHz (1 GHz typ.)
- Typical IF rejection > 90dB; Typical image suppression: 90 dB (≤9 GHz), >60 dB (≤20 GHz);
- Channel power, ACPR, IM3, OBW, Phase noise Real-time spectrum analysis based on FPGA, 100% POI < 3us;
- Analogue modulation analysis: AM/FM; Time domain IQ, PvT, real-time spectrum R&P;
- Weight: 2.5 kg, 10.1-inch all touch screen
- Battery life: 3h+, support power bank supply;
- 3 years warranty. HDMI interface support, expandable desktop station.
Real Portable · Real Performance · Real Affordable
HAROGIC PXR series is the latest rugged handheld spectrum analyzer with IP68 standard design. With its IP68-rated enclosure, it delivers unparalleled durability, ensuring reliable performance in extreme conditions—dust, water, and shock. Featuring frequency range of 9 kHz to 40 GHz and an analytical bandwidth of 100 MHz, the PXR series handheld rugged spectrum analyzer guarantees reliable and accurate measurement anywhere and anytime.
Building on continuous innovation and SWaP-C design principle, the PXE-200R offers an unmatched combination of size, performance and cost. RF measurements and analysis from 9kHz to 20 GHz is now carried out in a robust instrument with 10.1-inch full-touch screen and weight only 2.5kg. PXE-200R is a 20GHz real-time spectrum analyzer with analytical bandwidth of 100 MHz and ultra-fast speed of 900 GHz/s, delivering standard spectrum sweep (SWP), IQ streaming (IQS), zero span (DET) and real -time analysis (RTA) working mode. The PXE-200R is equipped with preamplifier and 19-segment preselector, achieving good dynamic range and phase noise level. It can provide customers with spectrum analyzer, spectrum monitoring, interference finding, RF test and measurement functions.
Working model overview
Standard Spectrum Mode - This mode Provides standard spectrogram, waterfall graph, probability density graph, phase noise graph and other measurement graphs. It offers measurement functions such as channel power, adjacent channel suppression, occupied bandwidth, XdB bandwidth, phase noise, and IM3.
IQ Streaming Mode - This mode provides time domain and spectrum view of IQ waveform, DDC function and AM/FM demodulation function, and delivers modulation depth and modulation frequency offset test.
Power Detection Mode (Zero Span) - This mode provides power time diagram (PvT) and its scaling, timing trigger, level trigger and other triggers.
Real-time Spectrum Analysis Mode - This mode provides spectrum, probability density graph, waterfall graph and other measurement graphs. It offers timing trigger, level trigger and other triggers.
OPTIONS – contact us for information:
- 01 Built-in OCXO reference clock
- 34 External omnidirectional antenna, 400-8000MHz, Gain<2dBi
- 40 T1 temperature class
- 71 Basic digital modulation analysis
- 72 Pulse signal measurement
| Product Name | Frequency | Phase Noise @10 kHz, 1.0 GHz Carrier | DANL | Resolution Bandwidth | Analysis Bandwidth | Lambda Part Number |
| PXN-400R | 9 kHz – 40 GHz | -107 dBc/Hz | -161 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80367 |
| PXN-400 Z | 9 kHz – 40 GHz | -107 dBc/Hz | -161 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80364 |
| PXN-400 | 9 kHz – 40 GHz | -107 dBc/Hz | -161 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 77186 |
| PXE-200R | 9 kHz – 20 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80366 |
| PXE-200 Z | 9 kHz – 20 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80363 |
| PXE-200 | 9 kHz – 20 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 76978 |
| PXE-90R | 9 kHz – 9.5 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80365 |
| PXE-90 Z | 9 kHz – 9.5 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 80362 |
| PXE-90 | 9 kHz – 9.5 GHz | -100 dBc/Hz | -168 dBm/Hz | 0.1 Hz-10 MHz | 100 MHz | 78702 |
